Product description
Compressors Danfoss R134a SC21G
Singlepack kits are complete compressor kits with all electrical and mounting accessories required for an installation or replacement. The singlepack lists provide the code numbers that are included in the kits. For comprehensive technical data on these code numbers, please refer to the individual code numbers.
TECHNICAL DATA
|
Model |
Displacement |
Refrigerant | Voltage | Evaporating temperature range |
Lubricant |
Weight | Max. Height |
| SC21G | 20,95 cm3 | R-134a | 198-254V / 50Hz | -35°C~+15°C |
- /550 ml |
15,5 kg | 219 mm |
Cooling Capacity
Model |
Evaporating Temp. / Cooling Capacity R-134a |
|||||||||
|
Condensing Temp. |
-25ºC | -20ºC | -15ºC | -10ºC | -5ºC | 0ºC | +5ºC | +10ºC | +15ºC | |
| SC21G | 55 ºC | 333 W | 453 W | 606 W | 792 W | 1012 W | 1268 W | 1560 W | 1889 W | 2256 W |
