Compressors Danfoss R134a TLS5FT 195B0321

Hermetic compressor for small refrigerating systems.

Producer: DANFOSS

Product code: SPDA_00042

Series:Danfoss 35

Size:

Our price:

207,43 €

/ pc.

168,64 €

net / pc.

Quantity:

Compressors Danfoss R134a TLS5FT 195B0321

Singlepack kits are complete compressor kits with all electrical and mounting accessories required for an installation or replacement. The singlepack lists provide the code numbers that are included in the kits. For comprehensive technical data on these code numbers, please refer to the individual code numbers.

TECHNICAL DATA

Model	Displacement	Refrigerant	Voltage	Evaporating temperature range	Lubricant (Charge/Type)	Weight	Max. Height
TLS5FT	5,08 cm³	R-134a	187-254V / 50Hz	-35°C~-10°C	- /180 ml	8,0 kg	173 mm

Cooling Capacity


Model	Evaporating Temp. / Cooling Capacity R-134a
Model	Condensing Temp.	-35^oC	-30^oC	-25ºC	-20ºC	-15ºC	-10ºC
TLS5FT	55 ºC	47,8 W	70,7 W	98 W	131 W	170 W	216 W

Tech specs:

Pictures:	illustrative

Technical data Download
