Compressors Danfoss R134a SC18FTX 195B0408

Hermetic compressor for small refrigerating systems.

Producer: DANFOSS

Product code: SPDA_00046

Series:Danfoss 35

Size:

Our price:

333,08 €

/ pc.

270,80 €

net / pc.

Quantity:

Compressors Danfoss R134a SC18FTX 195B0408

Singlepack kits are complete compressor kits with all electrical and mounting accessories required for an installation or replacement. The singlepack lists provide the code numbers that are included in the kits. For comprehensive technical data on these code numbers, please refer to the individual code numbers.

TECHNICAL DATA

Model	Displacement	Refrigerant	Voltage	Evaporating temperature range	Lubricant (Charge/Type)	Weight	Max. Height
SC18FTX	17,69 cm³	R-134a	187-254V / 50Hz	-35°C~-5°C	- /550 ml	14,2 kg	219 mm

Cooling Capacity


Model	Evaporating Temp. / Cooling Capacity R-134a
Model	Condensing Temp.	-35^oC	-30^oC	-25ºC	-20ºC	-15ºC	-10ºC	-5^oC
SC18FTX	55 ºC	144 W	229 W	325 W	437 W	567 W	719 W	896 W

Tech specs:

Pictures:	illustrative

Technical data Download
