Compressors Danfoss R134a SC10GH 195B0142

Hermetic compressor for small refrigerating systems.

Producer: DANFOSS

Product code: SPDA_00059

Series:Danfoss 35

Size:

Our price:

327,43 €

/ pc.

266,20 €

net / pc.

Quantity:

Compressors Danfoss R134a SC10GH 195B0142

Singlepack kits are complete compressor kits with all electrical and mounting accessories required for an installation or replacement. The singlepack lists provide the code numbers that are included in the kits. For comprehensive technical data on these code numbers, please refer to the individual code numbers.

TECHNICAL DATA

Model	Displacement	Refrigerant	Voltage	Evaporating temperature range	Lubricant (Charge/Type)	Weight	Max. Height
SC10GH	10,29 cm³	R-134a	198-254V / 50Hz	-15°C~+15°C	- /500 ml	12,7 kg	199 mm

Cooling Capacity


Model	Evaporating Temp. / Cooling Capacity R-134a
Model	Condensing Temp.	-15ºC	-10ºC	-5ºC	0ºC	+5ºC	+10^oC	+15ºC
SC10GH	55 ºC	259 W	352 W	467 W	604 W	762 W	942 W	1144 W

Tech specs:

Pictures:	illustrative

Technical data Download
