Product description
Compressor Danfoss R404a NL7CLX
Singlepack kits are complete compressor kits with all electrical and mounting accessories required for an installation or replacement. The singlepack lists provide the code numbers that are included in the kits. For comprehensive technical data on these code numbers, please refer to the individual code numbers.
TECHNICAL DATA
|
Model |
Displacement |
Refrigerant | Voltage | Evaporating temperature range |
Lubricant |
Weight | Max. Height |
| NL7CLX | 7,27 cm3 | R-404A/R507 | 198-254V / 50Hz | -45°C~-10°C |
- /320 ml |
11,0 kg | 203 mm |
Cooling Capacity
Model |
Evaporating Temp. / Cooling Capacity R-404A/R507 |
|||||||||
|
Condensing Temp. |
-45ºC | -40ºC | -35ºC | -30ºC | -25ºC | -20ºC | -15ºC | -10ºC | -5ºC | |
| NL7CLX | 45 ºC | 102 W | 146 W | 199 W | 263 W | 340 W | 430 W | 536 W | 657 W | 796 W |
