Compressor Danfoss R404a SC10CLX 195B0074

  • Hermetic compressor for small refrigerating systems.
  • Compressor Danfoss R404a SC10CLX 195B0074
Producer: DANFOSS
Product code: 195B0074
Series:Danfoss 20
302,69 €
/ pc.
246,09 €
net / pc.
Add to wish list

This product is available in our stores

You can buy this product without placing an online order at one of our stores in your area. Check where the product is in stock.
Check availability

Compressor Danfoss R404a SC10CL


Singlepack kits are complete compressor kits with all electrical and mounting accessories required for an installation or replacement. The singlepack lists provide the code numbers that are included in the kits. For comprehensive technical data on these code numbers, please refer to the individual code numbers.


TECHNICAL DATA


Model

Displacement

 Refrigerant Voltage Evaporating
temperature range

Lubricant
(Charge/Type)

 Weight Max. Height
SC10CL 10,29 cm3 R-404A/R507 198-254V / 50Hz -35°C~-10°C

- /550 ml

 13,4 kg 209 mm

Cooling Capacity



Model

Evaporating Temp. / Cooling Capacity R-404A/R507

Condensing Temp.

 -45ºC -40ºC -35ºC -30ºC -25ºC -20ºC -15ºC -10ºC -5ºC
SC10CL 45 ºC - - 168 W 258 W 365 W 489 W 634 W 800 W 991 W


Tech specs:
Factory flooded with oil:
Yes
Pictures:
illustrative
