Compressor Danfoss R404a FR6DL 195B0032

  • Hermetic compressor for small refrigerating systems.
  • Compressor Danfoss R404a FR6DL 195B0032
Producer: DANFOSS
Product code: SPDA_00095
Series:Danfoss 35
205,30 €
/ pc.
166,91 €
net / pc.
Add to wish list
Product description
Technical specification
Download
Reviews (0)
Ask a question
Product description

Compressors Danfoss R404a FR6DL



Singlepack kits are complete compressor kits with all electrical and mounting accessories required for an installation or replacement. The singlepack lists provide the code numbers that are included in the kits. For comprehensive technical data on these code numbers, please refer to the individual code numbers.

TECHNICAL DATA


Model

Displacement

Refrigerant Voltage Evaporating
temperature range

Lubricant
(Charge/Type

Weight Max. Height
FR6DL 6,23 cm3 R-404A/R507 198-254V / 50Hz -20°C~+15°C

- /450 ml

11,5 kg 196 mm

Cooling Capacity



Model

Evaporating Temp. / Cooling Capacity R-404A/R507

Condensing Temp.

-20ºC -15ºC -10ºC -5ºC 0ºC +5ºC +10ºC +15ºC
FR6DL 45 ºC 317 W 385 W 471 W 576 W 698 W 840 W 999 W 1177 W
