Compressor Danfoss R404a SC15DL 195B0089

  • Hermetic compressor for small refrigerating systems.
  • Compressor Danfoss R404a SC15DL 195B0089
Producer: DANFOSS
Product code: 195B0089
Series:Danfoss 20
310,55 €
/ pc.
252,48 €
net / pc.
Add to wish list

This product is available in our stores

You can buy this product without placing an online order at one of our stores in your area. Check where the product is in stock.
Check availability

Compressors Danfoss R404a SC15DL



Singlepack kits are complete compressor kits with all electrical and mounting accessories required for an installation or replacement. The singlepack lists provide the code numbers that are included in the kits. For comprehensive technical data on these code numbers, please refer to the individual code numbers.

TECHNICAL DATA


Model

Displacement

 Refrigerant Voltage Evaporating
temperature range

Lubricant
(Charge/Type

 Weight Max. Height
SC15DL 15,28 cm3 R-404A/R507 198-254V / 50Hz -20°C~+15°C

- /600 ml

 15,5 kg 219 mm

Cooling Capacity



Model

Evaporating Temp. / Cooling Capacity R-404A/R507

Condensing Temp.

 -20ºC -15ºC -10ºC -5ºC 0ºC +5ºC +10ºC +15ºC
SC15DL 45 ºC 759 W 964 W 1207 W 1493 W 1825 W 2210 W 2652 W 3156 W
Tech specs:
Factory flooded with oil:
Yes
Pictures:
illustrative
