Suction pressure regulator Danfoss KVL 28 034L0046

  • Regulating range 0.2 - 6.0 bar, factory setting 2 bar, max. working pressure 18 bar.
  • Schraeder valve for pressure testing.
  • Suction pressure regulator Danfoss KVL 28 034L0046
  • Suction pressure regulator Danfoss KVL 28 034L0046
  • Suction pressure regulator Danfoss KVL 28 034L0046
Producer: DANFOSS
Product code: AUDA_3312
Series:Danfoss_38_40
451,41 €
/ pc.
367,00 €
net / pc.
Add to wish list

This product is available in our stores

You can buy this product without placing an online order at one of our stores in your area. Check where the product is in stock.
Check availability

Suction pressure regulator Danfoss KVL 28 034L0046



Regulating range 0.2 - 6.0 bar, factory setting 2 bar,  max. working pressure 18 bar. Schraeder valve for pressure testing.





Tech specs:
Czynnik(i):
HFC
Maksymalne ciśnienie próbne:
19,8 bar
Maximum operating pressure:
18,0 bar
Inlet size:
1 1/8"
Rozmiar wylotowy:
1 1/8"
Typ:
KVL 28
Type of inlet connection:
Do lutowania, ODF
Outlet connection type:
Do lutowania, ODF
Ustawienia fabryczne:
2,00 bar
Wartość Kv [m/h]:
8,00
Wydajność znamionowa R134a:
13,20 kW
Wydajność znamionowa R22:
17,80 kW
Wydajność znamionowa R404A/R507:
15,90 kW
Wydajność znamionowa R407C:
16,40 kW
Regulation range:
0,2 - 6,0 bar
Zakres temp. medium:
-60 - 130 °C
Pictures:
illustrative
