Suction pressure regulator Danfoss KVL 35 034L0052

Regulating range 0.2 - 6.0 bar, factory setting 2 bar, max. working pressure 18 bar.
Schraeder valve for pressure testing.

Producer: DANFOSS

Product code: AUDA_3316

Series:Danfoss_38_40

Size:

uniwersalny

Our price:

487,08 €

/ pc.

396,00 €

net / pc.

Quantity:

Add to wish list

Suction pressure regulator Danfoss KVL 35 034L0052

SERVICE MANUAL

Regulating range 0.2 - 6.0 bar, factory setting 2 bar, max. working pressure 18 bar. Schraeder valve for pressure testing.

Characteristic	Value
Type	KVL 35
Factory setting	2,00 bar
Inlet connection type	Solder, ODF
Inlet size	1 3/8"
Inlet size	35 mm
Kv value [m/h]	8,00
Max. Test pressure	19,8 bar
Max. Working Pressure	18,0 bar
Medium temperature range	-60 - 130 °C
Outlet connection type	Solder, ODF
Outlet size	1 3/8"
Outlet size	35 mm
Rated capacity R134a	13,20 kW
Rated capacity R22	17,80 kW
Rated capacity R404A/R507	15,90 kW
Rated capacity R407C	16,40 kW
Refrigerant(s)	HCFC
Refrigerant(s)	HFC
Regulating range	0,2 - 6,0 bar

Tech specs:

Pictures:	illustrative
