Burn-out filter drier Danfoss DAS 164sW Solder 023Z1009

  • Burn-out filter drier for fluorinated refrigerants.
  • Burn-out filter drier Danfoss DAS 164sW Solder 023Z1009
  • Burn-out filter drier Danfoss DAS 164sW Solder 023Z1009
Producer: DANFOSS
Product code: 023Z1009
Series:Filtry - Danfoss
101,11 €
/ pc.
82,20 €
net / pc.
Add to wish list

This product is available in our stores

You can buy this product without placing an online order at one of our stores in your area. Check where the product is in stock.
Check availability

Burn-out filter drier Danfoss DAS 164sW Solder 023Z1009





Burn-out filter drier for fluorinated refrigerants.
70% activated alumina and 30% Molecular Sieve for adsorption of acid and moisture.
2 Schraeder access valves to measure pressure drop across the drier.
Max. working pressure: 35 bar.
120 mesh wire mesh for solid particle retention.





Tech specs:
Part number:
023Z1009
Pojemność nominalna:
360 cm3
Powierzchnia bloku filtrującego :
220 cm2
Przyłącza ODS,:
1/2"
PS:
35 bar
TS (min ~ max) :
-40 ~ 70°C
Pictures:
illustrative
Możłiwość zwrotu:
brak
