Burn-out filter drier Danfoss DAS 166sW Solder 023Z1011

  • Burn-out filter drier for fluorinated refrigerants.
  • Burn-out filter drier Danfoss DAS 166sW Solder 023Z1011
  • Burn-out filter drier Danfoss DAS 166sW Solder 023Z1011
Producer: DANFOSS
Product code: AUDA_6910
Series:Filtry - Danfoss
101,11 €
/ pc.
82,20 €
net / pc.
Add to wish list

Burn-out filter drier Danfoss DAS 166sW Solder 023Z1011

Burn-out filter drier for fluorinated refrigerants.
70% activated alumina and 30% Molecular Sieve for adsorption of acid and moisture.
2 Schraeder access valves to measure pressure drop across the drier.
Max. working pressure: 35 bar.
120 mesh wire mesh for solid particle retention.



Characteristic

Value

Catalogue number

023Z1011

Solid core surface

220 cm2

Nominal capacity

360 cm3

Inlet connection size ODS

3/4"

TS  (min ~ max)

-40 ~ 70°C

PS

35 bar



Tech specs:
Pictures:
illustrative
