Orifice Danfoss nr 13 TE55 067G2710

  • Orifice for Thermostatic Valves
  • Orifice Danfoss nr 13 TE55 067G2710
Producer: DANFOSS
Product code: 067G2707
Series:Danfoss_38_40
337,02 €
/ pc.
274,00 €
net / pc.
Add to wish list

This product is available in our stores

You can buy this product without placing an online order at one of our stores in your area. Check where the product is in stock.
Check availability

Danfoss nozzle No. 13 for TE55 067G2710

Nominal capacity is determined at:

Evaporation pressure te= +5°C for N (-40 - 10°C) and te = -30°C for B (-60 - -20°C).
Condensing temperature tc = +32°C.
Temperature of the liquid medium before the valve tl = +28°C.

Tech specs:
Rozmiar dyszy:
12
Wydajność znamionowa R134a, Zakres N [kW]:
166,00 KW
Wydajność znamionowa R22, Zakres B [kW]:
117,00 kW
Wydajność znamionowa R22, Zakres N [kW]:
245,00 kW
Wydajność znamionowa R404A, Zakres B [kW]:
71,90 kW
Wydajność znamionowa R404A, Zakres N [kW]:
182,00 KW
Wydajność znamionowa R407C, Zakres N [kW]:
232,00 KW
Wydajność znamionowa R507, Zakres B [kW]:
71,90 kW
Wydajność znamionowa R507, Zakres N [kW]:
182,00 KW
Application:
TE55
Pictures:
illustrative
