Compressor Aspera NT6217GK

  • Compressor Aspera for small refrigeration units.
  • Compressor Aspera NT6217GK
Producer: ASPERA (EMBRACO)
Product code: SPAS_319
Series:Agregaty i sprężarki Embraco
263,02 €
/ pc.
213,84 €
net / pc.
Add to wish list
Compressor Aspera NT6217GK

TECHNICAL DATA

Model

Displacement

 Refrigerant Voltage

Evaporating
temperature range

Lubricant (Charge/Type)

Weight Max. Height
NT6217GK 12,55 cm3 R404A/R507 230V/50Hz -20°C~+10°C

POE 22 /450 ml

16,7 kg

 220 mm

Cooling Capacity



Model

Evaporating Temp. / Cooling Capacity R404A/R507

Condensing Temp.

-20ºC

 -15ºC -10ºC -5ºC 0ºC +5ºC +10ºC
NT6217GK 55 ºC -
 -
 699 W 870 W 1078 W 1321 W 1599 W
45 ºC 590 W 734 W 920 W 1148 W 1415 W 1719 W 2062 W


Download

CATALOG



Tech specs:
Nominal capacity:
1779 W
Refrigerant:
R-404a
volume:
12,55 cm3
Power supply:
230 V / 50 Hz
Temperature range:
-20°C ~ +10°C
Oil Type:
POE 22 / 450 ml
Weight:

net

16,7 kg
Max. Height:
220,0 mm
Factory flooded with oil:
Yes
Pictures:
illustrative
