CompressorScroll Sanyo C-SBN373H8A 14,50 kW R407C 400V

  • Compressor Scroll Panasonic
  • CompressorScroll Sanyo C-SBN373H8A 14,50 kW R407C 400V
Producer: Panasonic
Product code: SPSC_091
Series:Sprężarki scroll Panasonic
Add to wish list

Compressor Scroll Sanyo C-SBN373H8A 14,50 kW R407C 400V

TECHNICAL DATA

Model

Displacement

Refrigerant

 Voltage Evaporating
temperature range

Lubricant typ

 Weight Sound
level
C-SBN373H8A 83,2 cm3 R407C,R404a
R134a,R407F		 380-415V / 50Hz M/HBP

FV68S

 38 kg 62 dB

Cooling Capacity


Model

Evaporating Temp. / Cooling Capacity R407C

Condensing Temp.

 -15ºC -10ºC -6,7ºC 0ºC +4,4ºC +7,2ºC +10ºC +12ºC
C-SBN373H8A 54,4 ºC - 7,14 kW 8,18 kW 10,78 kW 12,92 kW 14,50 kW 16,27 kW 17,67 kW
45 ºC 6,80 kW 8,33 kW 9,51 kW 12,47 kW 14,90 kW 16,68 kW 18,68 kW 20,25 kW



TECHNICAL DRAWING





Tech specs:
Factory flooded with oil:
Yes
Pictures:
illustrative
