Compressor Aspera NEK1118Z
TECHNICAL DATA
Model |
Displacement |
Refrigerant | Voltage |
Evaporating |
Lubricant (Charge/Type) |
Weight | Max. Height |
NEK1118Z | 8,39 cm3 | R-134a | 230V/50Hz | -30°C~-5°C |
POE 22 /350 ml |
10,7 kg |
200 mm |
Cooling Capacity
Model |
Evaporating Temp. / Cooling Capacity R-134a |
||||||
Condensing Temp. |
-30ºC | -25ºC | -20ºC | -15ºC | -10ºC | -5ºC | |
NEK1118Z | 55 ºC | 120 W | 163 W | 217 W | 283 W | 357 W | 446 W |
45 ºC | 144 W | 195 W | 256 W | 328 W | 417 W | 519 W |
Download
Tech specs:
Nominal capacity: | 224 W |
Refrigerant: | R-134a |
volume: | 8,39 cm3 |
Power supply: | 230 V / 50 Hz |
Temperature range: | -30°C ~ -5°C |
Oil Type: | POE 22 / 350 ml |
Weight:![]() net | 10,7 kg |
Max. Height: | 200 mm |
Factory flooded with oil: | Yes |
Pictures: | illustrative |
