VOLTAGE TESTER 750-2 TESTO 0590 7502
With the testo 750-2 voltage tester you can test electrical systems and equipment reliably and easily for voltage or de-energization thanks to the all-round LED display and unique fibre-optic technology. Compared to the testo 750-1, it is also suitable for single pole voltage testing to determine quickly whether conductors are live.
Tech specs:
Dimensions: | 270 x 70 x 35 mm |
Protection class: | IP64 |
Warranty: | 2 years |
Weight: net | 295 g |
Overvoltage Category: | CAT IV 600V; CAT III 1000V |
Authorizations: | TÜV; CSA; CE |
Measuring range (DC): | 12 do 690 V / 12 V, 24 V, 50 V, 120 V, 230 V, 400 V, 690 V |
Accuracy (DC): | according to DIN EN 61243-3:2010 |
Measuring range (AC): | 12 do 690 V / 12 V, 24 V, 50 V, 120 V, 230 V, 400 V, 690 V |
Accuracy (AC): | according to DIN EN 61243-3:2010 |
Continuity testing: | yes |
RDC/RC trigger function: | yes |
Rotating magnetic field testing: | yes |
Single pole phase testing: | yes |
Measuring point illumination: | yes |
Pictures: | illustrative |
