Condensing unit Tecumseh TAGDT 4590 ZHR TZ

Name: Condensing unit Tecumseh TAGDT 4590 ZHR TZ
Brand: Tecumseh
Price: 4815.45 EUR
Availability: OutOfStock

Producer: Tecumseh

Product code: AGLH_00031

Series:Agregaty i sprężarki Tecumseh

Size:

uniwersalny

Our price:

4 815,45 €

/ pc.

3 915,00 €

net / pc.

Quantity:

Add to wish list

Condensing unit Tecumseh TAGDT 4590 ZHR TZ

COOLING CAPACITY


Model	Evaporating Temp. / Cooling Capacity R404A/R507
Model	Ambient temp.	-25ºC	-20ºC	-15ºC	-10ºC	-5ºC	0ºC	+5ºC	+10ºC	+15ºC
TAGDT 4590 ZHR TZ	32 ºC	5409 W	7456 W	9783 W	12367 W	15167 W	18131 W	21192 W	24274 W	27307 W

Tech specs:

Part number:	TAGDT 4590 ZHR TZ
volume:	180,40 cm3
Nominal capacity:	12367 W (-10ºC/+32ºC)
Refrigerant:	R404A , R452A , R448A , R449A
Power supply:	380 V / 50 Hz
Temperature range:	-25°C~+15°C
Fan motors:	2 x 420 mm
Liquid receiver capacity:	9,5 L
Weight: net	175,00 cm3
Pictures:	illustrative
