Condensing unit Tecumseh TAGDT 4612 ZHR TZ

Name: Condensing unit Tecumseh TAGDT 4612 ZHR TZ
Brand: Tecumseh
Price: 6070.05 EUR
Availability: OutOfStock

Producer: Tecumseh

Product code: AGLH_00034

Series:Agregaty i sprężarki Tecumseh

Size:

uniwersalny

Our price:

6 070,05 €

/ pc.

4 935,00 €

net / pc.

Quantity:

Add to wish list

Condensing unit Tecumseh TAGDT 4612 ZHR TZ

COOLING CAPACITY


Model	Evaporating Temp. / Cooling Capacity R404A/R507
Model	Ambient temp.	-25ºC	-20ºC	-15ºC	-10ºC	-5ºC	0ºC	+5ºC	+10ºC	+15ºC
TAGDT 4612 ZHR TZ	32 ºC	7624 W	10208 W	13119 W	16334 W	19808 W	23472 W	27228 W	30961 W	34559 W

Tech specs:

Part number:	TAGDT 4612 ZHR TZ
volume:	225,00 cm3
Nominal capacity:	16334 W (-10ºC/+32ºC)
Refrigerant:	R404A , R452A
Power supply:	380 V / 50 Hz
Temperature range:	-25°C~+15°C
Fan motors:	2 x 500 mm
Liquid receiver capacity:	9,5 L
Weight: net	205 kg
Pictures:	illustrative
