Danfoss Maneurop Compressor MTZ40

  • Hermetic reciprocating compressor.
  • Danfoss Maneurop Compressor MTZ40
Producer: DANFOSS
Product code: SPMA_020
Series:Sprężarki niebieskie Danfoss Maneurop
1 697,40 €
/ pc.
1 380,00 €
net / pc.
Add to wish list
Danfoss Maneurop Compressor  MTZ40

TECHNICAL DATA

Model

Displacement

 Refrigerant Voltage Connection

Lubricant (Charge/Type)

 Weight
MTZ40 67.9 cm3

R404A - R507A -
R134a - R407C

 400V / 50Hz &
460V / 60 Hz		 Rotalock

POE - 160PZ / 1l

 26 kg

Cooling Capacity



Model

Evaporating Temp. / Cooling Capacity R-404A

Condensing Temp.

 -30ºC -25ºC -20ºC -15ºC -10ºC -5ºC 0ºC +5ºC +10ºC
MTZ40 55 ºC - 1616 W 2300 W 3101 W 4040 W 5141 W 6427 W 7918 W 9638 W
45 ºC  1601 W 2316 W 3161 W 4159 W 5333 W 5704 W 8294 W 10128 W 12225 W











Tech specs:
Part number:
MTZ40JH4AVE
,
MTZ40-4VI
,
MTZ40-4VM
Wydajność wolumetryczna:
11,8 m3/h (2900 obr/min)
Displacement:
67,89 cm3
Refrigerant:
R404a / R507A / R134a / R407C / R407A / R407F
Oil Type:
POE 160PZ / 1l
Factory flooded with oil:
Yes
Weight:

net

26 kg
Pictures:
illustrative
