Olvent Pull Fan YWF6D-910S-180/100-G 380V

The fans used in condensers and chillers.

Producer: OLVENT

Product code: WEOA_023A

Series:Wentylatory - Olvent

Size:

Our price:

773,53 €

/ pc.

628,89 €

net / pc.

Quantity:

This product is available in our stores

You can buy this product without placing an online order at one of our stores in your area. Check where the product is in stock.

Check availability

Olvent Pull Fan YWF6D-910S-180/100-G 380V

OLVENT axial fans are used in air conditioning, ventilation, refrigeration, heating systems. A wide range of destination due to the large variety of fan: suction or blowing, single or three-phase power supply, diameter from 250 to 910 mm, as well as good qualities: a wide temperature range of application, any method of installation. In addition, to meet the requirements of the ErP Directive 2015 makes it possible to use fans in each application.

Tech specs:

Diameter:	910 mm
Rated speed:	Δ=910 Y=740 min-1
Power supply:	380 V / 50 Hz
Flow:	Suction
Air volume:	Δ=24101l Y=20836 m3/h
Current.:	Δ=3.75 Y=2.35 A
Input:	Δ=1800 Y=1400 W
IP Protection:	IP55 IP
Capacitor:	-
Sound level:	Δ=84 Y=78 dB(A)
Internal thermal protection:	150±5°C
Weight: net	50 kg
Directive ErP 2015:	✓
Pictures:	illustrative

Technical data Download
