Danfoss Performance Compressor SZ185S4RC

  • Hermetic scroll compressor.
  • Danfoss Performance Compressor SZ185S4RC
Producer: DANFOSS
Product code: SPMA_584
Series:Sprężarki niebieskie Danfoss Maneurop
6 273,00 €
/ pc.
5 100,00 €
net / pc.
Add to wish list
Danfoss Performance Compressor  SZ185S4RC

TECHNICAL DATA

Model

Displacement

 Refrigerant Voltage Connection

Lubricant
(Charge/Type)

 Weight
SZ185S4RC 249,9 cm3

 R407C -R134a -

(R404A - R507A)

 380-400V / 50Hz &
340-440V / 60 Hz		 Rotalock

POE - 160PZ / 6,2l

 100 kg

Cooling Capacity



Model

Evaporating Temp. / Cooling Capacity R-407C

Condensing Temp.

 -20ºC -15ºC -10ºC -5ºC 0ºC +5ºC +10ºC +15ºC
SZ185S4RC 55 ºC - - - 23340 W 29052 W 35667 W 43275 W 51964 W
45 ºC - 17169 W 21913 W 27478 W 33953 W 41427 W 49990 W 59730 W











Tech specs:
Nominal capacity:
23,77 kW
Dimensions:
Średnica : 317 mm
,
Wysokość : 678 mm
Power supply:
400V/3~/50Hz
Factory flooded with oil:
Yes
Pictures:
illustrative
