Compressor Aspera R134a NJ6226Z

  • Compressor Aspera for small refrigeration units.
  • Compressor Aspera R134a NJ6226Z
Producer: ASPERA (EMBRACO)
Product code: SPAS_709
Series:Agregaty i sprężarki Embraco
348,93 €
/ pc.
283,68 €
net / pc.
Add to wish list

This product is available in our stores

You can buy this product without placing an online order at one of our stores in your area. Check where the product is in stock.
Check availability
Compressor Aspera NJ6226Z
TECHNICAL DATA

Model

Displacement

 Refrigerant Voltage

Evaporating
temperature range

Lubricant (Charge/Type)

Weight Max. Height
NJ6226Z 34,38 cm3 R-134a 230V/50Hz -15°C~+10°C

POE 22 /750 ml

19,8 kg

 253 mm

Cooling Capacity


Model

Evaporating Temp. / Cooling Capacity R-134a

Condensing Temp.

 -15ºC -10ºC -5ºC 0ºC +5ºC +10ºC
NJ6226Z 55 ºC 868 W 1182 W 1531 W 1923 W 2371 W 2886 W
45 ºC 1144 W 1497 W 1892 W 2340 W 2852 W 3438 W




Download

CATALOG



Tech specs:
Nominal capacity:
2976 W
Refrigerant:
R-134a
volume:
34,38 cm3
Power supply:
230 V / 50 Hz
Temperature range:
-15°C ~ +10°C
Oil Type:
POE 22 / 750 ml
Weight:

net

19,8 kg
Max. Height:
253,0 mm
Factory flooded with oil:
Yes
Pictures:
illustrative
