Compressor Aspera NEK6144GK

  • Compressor Aspera for small refrigeration units.
  • Compressor Aspera NEK6144GK
Producer: ASPERA (EMBRACO)
Product code: SPAS_283
Series:Agregaty i sprężarki Embraco
144,35 €
/ pc.
117,36 €
net / pc.
Add to wish list
Compressor Aspera NEK6144GK

TECHNICAL DATA

Model

Displacement

 Refrigerant Voltage

Evaporating
temperature range

Lubricant (Charge/Type)

Weight Max. Height
NEK6144GK 4,51 cm3 R404A/R507 230V/50Hz -20°C~+10°C

POE 22 /350 ml

10,4 kg

 187 mm

Cooling Capacity



Model

Evaporating Temp. / Cooling Capacity R404A/R507

Condensing Temp.

-20ºC

 -15ºC -10ºC -5ºC 0ºC +5ºC +10ºC
NEK6144GK 55 ºC -
 -
 314 W 384 W 465 W 559 W 666 W
45 ºC 271 W 326 W 395 W 480 W 580 W 694 W 825 W


Download

CATALOG



Tech specs:
Nominal capacity:
714 W
Refrigerant:
R-404a
volume:
4,51 cm3
Power supply:
230 V / 50 Hz
Temperature range:
-20°C ~ +10°C
Oil Type:
POE 22 / 350 ml
Weight:

net

10,4 kg
Max. Height:
187 mm
Factory flooded with oil:
Yes
Pictures:
illustrative
